R19IHAT-66EX 19英寸 Intel® Core™ i5/i7 防爆等级工业计算机
重点特色
- 19英寸 1000 nits LCD 显示器
- Class 1, Division 2 & ATEX Zone 2 防爆等级应用认证
- Intel® Haswell Core™ i5-4300U (选配i7-4650U)
- 无风扇设计，带流线型外壳，实现高效散热
- 智慧加热器用于在极端寒冷环境中工作温度达 -40°C
- CERTIFICATIONS
-
经认证可用于危险场所
R19IHAT-66EX是经ATEX 2区认证的电脑，用于远程数据收集、过程可视化和控制。适合部署在ATEX区，安全是首要任务。
高处理能力和无风扇散热系统
来自Intel® Core™ i5/i7处理器的高性能计算，用于最苛刻的任务。散热系统是无风扇的，具有流线型外壳，可实现高效的散热。
完全坚固和防水的设计
R19IHAT-66EX ATEX工业电脑提供全面的IP66防尘防水保护，可承受振动，并符合MIL-STD-810F标准要求。适用于车载应用和潜在的爆炸性环境。所有的I/O端口都被盖子覆盖，带有EX-Type黄铜电缆接头M16/M12，在潮湿和多尘的操作条件下提供最大的保护。
适用于极端工作条件下的操作
R19IHAT-66EX ATEX工业电脑内置智能加热器，可从-40°C提升到70°C，适合在户外或危险环境下的酷热或严寒环境下操作。
终极触控体验
通过支持多点触控的投射电容触控，增强客户体验，可以轻松地用手指控制。使用R19IHAT-66EX时，享受每一次触控和便利，并在一些最苛刻的应用中体验极致的耐用性，如钻机的控制面板。
Processor
Intel Core i5-4300U 1.9GHz (up to 2.9GHz) Intel Core i7-4650U 1.7GHz (up to 3.3GHz) (Optional)
Memory
1 x SO-DIMM, DDR3L 1600 MHz, 4GB 8GB (Optional)
Storage
1 x mSATA SSD 128GB mSATA SSD up to 512GB (Optional) 1 x SATA III for 2.5" HDD (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 1.2
Operating System
Windows 7 Embedded Systems (Optional) Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 20.04 (Optional)
Touch / Glass
Projected Capacitive Multi Touch Screen Bonding With Panel
Size
19 inches
Resolution
1280x1024
Panel Brightness
800 nits 1000 nits(Optional)
Contrast Ratio
1000:1
View Angles
85,85,80,80
Active Area
376.32x301.06 mm
Dimension
474 x 410 x 111 mm
Cut out
462 x 386mm
Mounting
Panel mount VESA Mount
Enclosure
Aluminum Housing
Cooling System
Fanless design
Operating Humidity
5% to 95% RH, Non-Condensing
Operating Temperature
-40°C to 70°C (with intelligent heater)
Storage Temperature
-40°C to 70°C
Shock
MIL-STD-810G Method 516.6 Procedure I
Vibration
MIL-STD-810G Method 514.6 Procedure I
IP rating
IP66 Meet Standard IEC60529 (for Non-Hazardous location) IP54 Meet Standard IEC60079 (for Hazardous location)
Certification
CE, FCC UL 60950-1 CSA C22.2 No. 60950-1-07 EN 62368-1 Class I, Div.2, Groups A,B,C,D T4 -40 <= Tamb <= 70 Meet Standards ANSI/ISA-12.12.01-2013 CSA Std. C22.2 No. 213-M1987 ATEX II 3G Ex nA ic IIC T4 Gc -40 <= Tamb <= 70 Meet Standards EN 60079-0, EN 60079-11, EN 60079-15 IECEx Ex nA ic IIC T4 Gc -40 <= Tamb <= 70 Meet Standards IEC 60079-0, IEC 60079-11, IEC 60079-15
USB Port
1 x USB2.0, 4-Pin Terminal Block
Serial Port
1 x RS232/422/485, 10-Pin Terminal Block
LAN
1 x LAN, , 8-Pin Terminal Block
Expansion Port
1 x mPCIe slot(for half size Wifi module) 1 x mPCIe slot(for SSD)
Indicator
1 x LED Indicator for power 1 x LED Indicator for storage 1 x LED Indicator for heater 1 x LED Indicator for LAN 1 x LED Indicator for lock touch
Gland
2 x EX-Type Brass Cable Gland M16 (Cable range 7.5~10.2mm) 3 x EX-Type Brass Cable Gland M12 (Cable range 5.4~8mm)
Power Input
1 x 9~36V DC, 3-Pin Terminal Block
Button
1 x Power Button 1 x Brightness up Button 1 x Brightness down Button 1 x Button for locking touch function 1 x Programmable function key
Accessory
24V 150W AC to DC Adapter Power cord Open wired power cable for M12 cable Gland Open wired LAN/COM cable for M16 cable Gland VESA Mounting Screws Mounting Clips & Screws 3 Pins Terminal Block For Power 8 Pins Terminal Block For LAN 4 Pins Terminal Block For USB 10 Pins Terminal Block For COM
Optional Accessory
SMA male to female extension cable for M12 cable Gland (Optional)
